Transformer Smart LED Driver Multiple Output Port Interface DC Power Supply

Basic Info.

Model NO.	ksd014
Power Supply Mode	Constant Voltage Source
Modulation System	PWM
In-Out	Step-down Type
Power Supply Voltage	AC85-265
Pack Sealing Size	SMD
Brand	Kashidi
Watt	24W/36W/48W/60W/80W/100W
Application	Cabinet Lighting
Housing	Plastic
Wire	Customized
Transport Package	Carton
Specification	168*60*20MM
Trademark	kashidi
Origin	China
Production Capacity	50000 Per Week

Packaging & Delivery

Package Size 10.00cm * 10.00cm * 10.00cm Package Gross Weight 0.500kg Lead Time 7 days (1 - 1 Pieces)
To be negotiated ( > 1 Pieces)

Product Description

Performance Parameters

Model		LGDD-12060
Output	Dc Voltage	12V
	Rated Current	2A /3A/5A
	Current Range	0~5A
	Rated Power	24W/36W/60W
	Ripple&Noise(Max)	150mV
	Voltage Tolerance	±4%
	Setup,Rise Time	100ms/220VAC
	Hold Up Time(Typ.)	80ms/220VAC
Input	Voltage Range	100~265VAC
	Frequency Range	47~60Hz
	Power Factor(Typ)	PF>0.6/220VAC
	Efficiency(Typ)	86%
	Short Circuit	Protection type: recovers automatically after fault conditions is removed
	Overlaod	Overload protection @145~160%above peak rating
	Over Temperature	protection typer:shut down o/p voltage.re-power on to recover
Environment	Working Temp	-20~50ºC
	Working Humidity	20~90% RH no-condensing (Waterproof)
	Storage Temp Humidity	-40~ +60ºC,10~90%RH
Safety&Emc	Safety Standards	CE Mark (LVD)
	Withstand Voltage	I/P-O/P:1.5KVAC IP-GND:1.5KVAC

NOTE
1. All parameters NOT specially mentioned are measured at 220VAC input,rated laod and 25ºC of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a12''twisted pair-wire terminated with a 0.1uf&10uf parallel capacitor. 3. Tolerance: includes set up tolerance,line regulation and load regulation.
RAQ:
Q1: Are you a manufacturer or a trade company?A1: We are a manufacturer , we have our own factory , we can guarantee the delivery and quality of our products.Q2. Can I have a sample order for led light?A2: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.Q3. What about the lead time?A3: Samples within 3 days, big order within 1-2 weeks.Q4. Do you have any MOQ limit for led light order?A4: Low MOQ, 1pc for sample checking is available.Q5. How do you ship the goods and how long does it take to arrive?A5: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.Q6. What about Payment?A6:Bank Transfer (TT), Paypal,Western Union,Trade assurance;30% the amount should be paid before producing,the balance 70% of the payment should be paid before shipping.Q7. Is it OK to print my logo on led light product?A7: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.Q8: How to deal with the faulty?A8: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.1%. Secondly,during the warranty period, we will repair or replace defected products.
