Overview

Basic Info.

Model NO.	PLH-96-24
Voltage Regulating Mode	Frequency Modulation Type
Power Supplying System	Terminal Power Distribution Equipment
Energy Transmission	One-way Transmission
Modulation System	PWM
Certification	CE, RoHS, ISO, UL/Rcm/SAA/FCC/IP67
Brand	Kmwell
Working Environment	-40~+60
Power Factor	>0.95
Protections	Ocp, Ovp, Otp
Efficiency	>92.8%
IP Rating	IP67
Transport Package	Export Cartons
Specification	188*60.5*39mm
Trademark	Kmwell
Origin	China
HS Code	85044014
Production Capacity	80000 PCS/Month

Product Description

Product Description

Features

• Constant voltage design
• AC Input voltage 90-305V
• High Power Factor PF≥0.95
• Aluminum shell, silicone potted
• Meet UL/CE/EMC/FCC/ROHS Certificate
• Protection : Over load / Over voltage / Short circuit / Over temperature
• IP67 design for outdoor installations
• 100% full load burn-in test
• Suitable for LED lighting and outdoor sign applications
• Dry and damp locations
• 5 years warranty

Product Parameters

Specification

Performance		Safety
Input voltage	120~277V AC	Over Current Protection	110~120%
Input Current	0.88A~0.4A	Short Circuit Protection	Hiccup mode, auto recover
Input Frequency	47~63Hz	Other Protection	Over voltage
Efficiency	[email protected] [email protected]	UL	UL879 UL8750
Power Factor	Normal		CSA C22.2 NO. 207-M89
Output Voltage	DC24V ± 3 %	CE-LVD	EN61347-1:2008+A1:2011+A2:2013
Output Current	0-4.0A		EN61347-2-13:2014
Output Power	96W Max.

Physical		Environmental
Length	188mm	CE-EMC	EN55015 EN61547 EN61000
Width	60.5mm	FCC	FCC 47 CFR PART 15,CLASS B
Height	39.0mm	IP Rating	IP67
Mounting Length	215mm	Operating Temperature	-40°C to 60°C(‐22°F to 140°F)
Weight	720g	Storage Temperature	-45°C to 85°C(‐40°F to 185°F)
Lead Lengths	220mm± 10mm	Relative Humidity	20 to +90% RH non cond

Certifications

Our Advantages

1,More than 20 years of experience in the design and production of industrial switching power supplies;2,All power products are exported, serving 48 countries and regions around the world, more than 90% are regular customers;3,We understand the special requirements of various fields of use, and our power products can meet various complex environmental requirements;4,We have a complete quality control system and quality traceability system to ensure 100% qualified products;5,We have a full range of testing and testing equipment. We have maintained many years of cooperative relations with major global component manufacturers, and our technology research and development remain at the cutting edge of the industry.;6,We have built a complete after-sales service system, with a warranty period ranging from 3 to 5 years. Quickly respond to various needs of customers.

Order Guide

Constant Voltage Series PLH-96W

Model Name	Input Voltage	Output Power	Output Current	Output Voltage	Efficiency
PLH-96-12	120-277Vac	96W	8.0A	12V	89.5%
PLH-96-24	120-277Vac	96W	4.0A	24V	91.0%
PLH-96-36	120-277Vac	96W	2.67A	36V	92.5%
PLH-96-48	120-277Vac	96W	2.0A	48V	93.0%

FAQ

Q: Can you make the products with our logo?
A: Yes, we provide the OEM and ODM product, so we can according to you requirement and put your logo on the label.
Q: Can your products work in the lowest temperatures of -20 degrees?
A: Yes, our LED power supply products are designed and produced according to the outdoor environment, waterproof level up to IP67, the minimum operating temperature - 40 degrees, can be used in most parts of the earth.
Q: What is your product warranty ?
A: All our aluminum shell products warranty is 5 years and plastic case products warranty is 3 years.
Q: Can I be your general agent in our country and region? Is there a marketing policy to support it?
A: Yes, We welcome customers all over the world to apply to become our agents, we will provide preferential prices and long-term payment to support your marketing.
